| Frame: | 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal BBX63 Cable Routing for Dropper Post and 12mm X 148mm Boost Dropouts |
| Fork: | RockShox Pike Select RC 27.5", 130mm Travel, 37mm Offset, DebonAir, Charger RC Damper, Fast Black Coating, Tapered Steerer, 110mm x 15mm Boost, Maxle Ultimate |
| Rear Shock: | N/A |
| Headset: | FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings |
| Rear Hub: | Alloy, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole |
| Front Hub: | Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 31mm Torque Caps, 32 Hole |
| Spokes: | DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples |
| Rims: | WTB ST i35 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole |
| Tyres: | Maxxis High Roller II TR 27.5" x 2.8" 120TPI, EXO Sidewall Protection, 3C Maxx Terra, Front, Maxxis Rekon TR 27.5" x 2.8" 60TPI, EXO Sidewall Protection, Rear |
| Shift Levers: | SRAM NX Eagle, MMX, 12 Speed |
| Front Derailleur: | N/A |
| Rear Derailleur: | SRAM NX Eagle, 12 Speed |
| Cassette: | SRAM PG-1230 Eagle, 11-50, 12 Speed |
| Chain: | SRAM NX Eagle, 12 Speed |
| Crankset: | SRAM X1 Eagle, X-SYNC 2, Direct Mount 32T, DUB, 170mm, Boost 12 Speed |
| Bottom Bracket: | SRAM DUB, BSA, 73mm |
| Seatpost: | KS RAGEi, 30.9mm, S/M 150mm, L/XL 170mm Travel, KS South Paw MMX Remote Lever |
| Seat: | Whyte Custom |
| Bar: | Whyte 6061 Alloy, 30mm Rise, 31.8mm, 780mm Wide |
| Stem: | Whyte Gravity Stem, 35mm Extension |
| Grips: | Whyte Lock-on Enduro Grip |
| Front Brakes: | SRAM Guide T, 4 Piston, 180mm Disc |
| Rear Brakes: | SRAM Guide T, 4 Piston, 180mm Disc |
| Brake Levers: | SRAM Guide T, Matchmaker |
| Pedals: | None |
