Colour: | Matt Black Burnt Orange/Grey |
Frame: | 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing, Shape.it Link and 12mm X 148mm Boost Dropouts |
Fork: | Fox Float 38, Factory 27.5", 180mm Travel, 44mm Offset with Grip 2 Damper and custom tune, Tapered Steerer, Kashima Coating, 110mm x 15mm Boost, E-Thru Axle |
Rear shock: | Fox Float X2, Factory, independently adjustable Compression and Rebound damping, Kashima coating |
Headset: | FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings |
Rear hub: | DT Swiss 350 Straightpull with 24T Ratchet System, 12mm x 148mm, 6 Bolt with Magnet carrier, 28 Hole |
Front hub: | DT Swiss 350, 15mm x 110mm, Centre-Lock, 28 Hole |
Spokes: | DT Swiss Hybrid triple butted 2.34mm/1.8mm/2.0mm, Black Stainless, DT Pro Lock Squorx Nipples |
Rims: | DT Swiss Hybrid 30, Sleeved Joint, 28 Hole |
Tyre: | Maxxis Assigai WT, TR, 27.5" x 2.5" 120TPI, EXO + Sidewall Protection, 3C Maxx Terra, Dual Compound, Folding Bead, Front, Maxxis Assigai WT, TR, 27.5" x 2.5" 120TPI, Double Down Casing, 3C Maxx Terra, Dual Compound, Rear |
Shift levers: | SRAM X01-E Eagle, Single Click, MMX, 12 Speed |
Front mech: | N/A |
Rear mech: | SRAM X01 Eagle, 12 Speed |
Cassette: | SRAM XG-1275 Eagle, 10-52, 12 Speed |
Chain: | SRAM GX Eagle, 12 Speed |
Crankset: | Race Face Affect E-Bike, 165mm, ISIS with X-SYNC Direct Mount 36T for Bosch Performance Line CX, Black |
Bottom bracket: | N/A |
Seatpost: | Crank Bro High-Line 3, 30.9mm, M/L 150mm Travel, XL 170mm Travel, High-Line Ball Socket Remote Lever |
Saddle: | Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
Handlebar: | Race Face Turbine R, 35mm Rise, 35mm Bar Bore, 800mm Wide |
Stem: | Race Face Atlas, 35mm Bar Bore, 35mm Extension |
Grips: | Whyte Lock-on Enduro Grip |
Brakes front: | SRAM Code RSC, 4 Piston with Sintered Metal Pads, 220mm Disc |
Brakes rear: | SRAM Code RSC, 4 Piston with Sintered Metal Pads, 200mm Disc |
Brake levers: | SRAM Code RSC, MMX |
Pedals: | None |
