Frame: | 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing, Shape.it Link and 12mm X 148mm Boost Dropouts |
Fork: | Fox Float 38, Performance 27.5", 160mm Travel, 44mm Offset with Grip Damper, 3pos Adjust and custom tune, Tapered Steerer, 110mm x 15mm Boost, E-Thru Axle |
Rear Shock: | Fox Float Performance DPS, Evol LV, 3pos adjustable Compression and Rebound damping |
Headset: | FSA No. 57E Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Sealed Cartridge Bearings |
Rear Hub: | Alloy, e-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole |
Front Hub: | Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 32 Hole |
Spokes: | DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples |
Rims: | WTB HTZ i30 TCS 2.0 System, Asymmetric, Sleeved Joint, Super Tough Construction, Tubeless Ready, 32 Hole |
Tyres: | Maxxis Assigai WT, TR, 27.5" x 2.5" 120TPI, EXO+ Casing, 3C Maxx Terra, Dual Compound, Front, Maxxis Minion DHR WT, TR, 27.5" x 2.4" 120TPI, Double Down, 3C Maxx Terra, Dual Compound, Folding Bead, Rear |
Shift Levers: | SRAM GX-E, Eagle, Single Click, MMX, 12 Speed |
Front Derailleur: | N/A |
Rear Derailleur: | SRAM X01 Eagle, 12 Speed |
Cassette: | SRAM XG-1275 Eagle, 10-52, 12 Speed |
Chain: | SRAM GX Eagle, 12 Speed |
Crankset: | SRAM EX1, 165mm, ISIS with X-SYNC 2, Direct Mount 36T for Bosch Performance Line CX, Black |
Bottom Bracket: | N/A |
Seatpost: | Crank Bro High-Line 3, 30.9mm, XS/S 125mm Travel, M/L 150mm XL 170mm Travel, High-Line Ball Socket Remote Lever |
Seat: | Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
Bar: | Whyte Custom 6061 Alloy, 30mm Rise, 35mm Bar Bore, 780mm Wide |
Stem: | Whyte Enduro Stem, 35mm Bar Bore, 35mm Extension |
Grips: | Whyte Lock-on Enduro Grip |
Front Brakes: | SRAM Code R, 4 Piston with Sintered Metal Pads, 220mm Disc |
Rear Brakes: | SRAM Code R, 4 Piston with Sintered Metal Pads, 200mm Disc |
Brake Levers: | SRAM Code R, MMX |
Pedals: | None |
