| Colour: | Matt olive and matt black |
| Frame: | 6061 alloy, hydroformed T6 aluminium, multi-butted, Single Chainring (SCR), tapered headtube, internal cable routing with BBX63, chainstay Post Mount (PM) dropouts and 12mm x 148mm Boost dropouts |
| Fork: | RockShox Recon RL 29in, 120mm travel, 42mm offset, Solo Air, Fast Black coating, adjustable rebound, tapered alloy steerer, 110mm x 15mm Boost, Maxle Lite |
| Rear shock: | N/A |
| Headset: | FSA No. 57B Orbit ZS, 1 1/2in lower and 1 1/8in upper caged bearings |
| Rear hub: | Alloy, double sealed cartridge bearings, 12mm x 148mm Boost spacing, 32 hole |
| Front hub: | Alloy, double sealed cartridge bearings, 15mm x 110mm Boost spacing, 32 hole |
| Spokes: | DT Swiss Champion 2.0mm, black stainless, brass nipples |
| Rims: | WTB ST i27 TCS 2.0 System, pinned joint, tubeless ready, 32 hole |
| Tyre: | Maxxis Ardent 29in x 2.4in EXO Dual Compound, 60TPI, tanwall |
| Shift levers: | SRAM SX Eagle |
| Front mech: | N/A |
| Rear mech: | SRAM SX Eagle, 12 speed |
| Cassette: | SRAM PG-1210 Eagle, 11-50T, 12 speed |
| Chain: | SRAM SX Eagle, 12 speed |
| Crankset: | SRAM X1 Eagle, X-SYNC 2, Direct Mount 32T, DUB, 170mm, Boost 12 speed |
| Bottom bracket: | SRAM DUB, BSA, 73mm |
| Seatpost: | KS 900i, 30.9mm (size S 125mm travel; sizes M-XL 150mm travel), Southpaw remote lever |
| Saddle: | Whyte Custom |
| Handlebar: | Whyte 6061 alloy, 15mm rise, 31.8mm bar bore, 780mm wide |
| Stem: | Whyte alloy, 45mm extension, 31.8mm bar bore |
| Grips: | Whyte Enduro lock-on |
| Brakes front: | Tektro HD-M535, four piston hydraulic, 2.3mm thick 180mm diameter disc rotor |
| Brakes rear: | Tektro HD-M535, four piston hydraulic, 2.3mm thick 180mm diameter disc rotor, internal routing |
| Brake levers: | Tektro M-535 |
| Pedals: | Fibre reinforced composite platform |
| Weight: | 14.6kg (size M) |
