COLOUR
|
Matt Burnt Orange Earth/Grey
|
CASSETTE
|
SunRace CSMS3, ED Black, 11-46, 10 Speed
|
|
FRAME
|
6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, SCR, Tapered Headtube, Get A Grip Seat Clamp System, Internal Cable Routing with BBX and Chainstay Post Mount Dropouts 10mm X 141mm Boost
|
CHAIN
|
SunRace 10 Speed
|
|
FORK
|
RockShox Recon RL 27.5", 120mm Travel, 37mm Offset, Solo Air, Fast Black Coating, Adjustable Rebound, Tapered Alloy Steerer, 110mm x 15mm Boost, Maxle Lite
|
CRANKSET
|
Whyte, Forged 2pcs Cranks, Direct Mount 30T Narrow Wide Chainring, 170mm, 10 Speed
|
|
REAR SHOCK
|
N/A
|
BOTTOM BRACKET
|
BSA, Cartridge Bearings, 73mm
|
|
HEADSET
|
FSA No. 57B Orbit ZS, 1 1/2" Lower and 1 1/8" Upper Caged Bearings
|
SEATPOST
|
Whyte 6061 Alloy, 15mm Offset, 30.9mm x 350mm, 2 Bolt Clamp
|
|
REAR HUB
|
Alloy, Double Sealed Cartridge Bearings, 10mm x 141mm QR Boost, with stealth axle, 32 Hole
|
SADDLE
|
Whyte Custom, Triple Panel Design
|
|
FRONT HUB
|
Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Through Axle, 32 Hole
|
HANDLEBAR
|
Whyte 6061 Alloy, 15mm Rise, 31.8mm, XS 740mm Wide, S/M 760mm Wide
|
|
SPOKES
|
DT Swiss Champion 2.0mm, Black Stainless, Brass Nipples
|
STEM
|
Whyte Alloy, 40mm Extension
|
|
RIMS
|
WTB ST i27 TCS 2.0 System, Pinned Joint, Tubeless Ready, 32 Hole
|
GRIPS
|
Whyte Lock-on V Grip
|
|
TYRE
|
Maxxis High Roller II TR 27.5"x 2.4" 60TPI, EXO Sidewall Protection, 3C Maxx Terra, Front, Maxxis Forekaster TR 27.5" x 2.35" 60TPI, EXO Sidewall Protection, Dual Compound, Rear
|
BRAKES FRONT
|
Tektro Auriga HD-M290, 180mm Rotor
|
|
SHIFT LEVERS
|
Shimano Deore SL-M6000, 10 Speed
|
BRAKES REAR
|
Tektro Auriga HD-M290, 180mm Rotor, Internal Routing
|
|
FRONT MECH
|
N/A
|
BRAKE LEVERS
|
Tektro Auriga HD-M290
|
|
REAR MECH
|
Shimano Deore RD-M6000-GS, Shadow Plus, 10 Speed
|
PEDALS
|
Fibre Reinforced Composite Platform
|
|
WEIGHT
|
12.8
|
|
|
