Colour: | Gloss Silver with Matt Black |
Frame: | 6061 Alloy, Hydro Formed T6 Aluminium, Multi Butted, Custom Drawn, Tapered Headtube, Internal Cable Routing, Shape.it Link and 12mm X 148mm Boost Dropouts |
Fork: | Fox Float 38, Performance, 160mm Travel, 44mm Offset with Grip Damper, 3pos Adjust, Tapered Steerer, 110mm x 15mm Boost, E-Thru Axle |
Rear shock: | Fox Float Performance DPS, Evol LV, Custom tuned for Whyte, 3pos adjustable Compression and Rebound damping |
Headset: | FSA No. 55/35 Orbit 1.5 ZS, 1.8" Lower and 1 1/8" Upper Sealed Cartridge Bearings |
Rear hub: | Alloy, e-bike specific, Double Sealed Cartridge Bearings, 12mm x 148mm Boost Thru Axle, 32 Hole |
Front hub: | Alloy, Double Sealed Cartridge Bearings, 15mm x 110mm Boost Thru Axle, 32 Hole |
Spokes: | DT Swiss New Champion 2.0mm, Black Stainless, Brass Nipples |
Rims: | WTB HTZ i30 TCS 2.0 System, Asymmetric, Sleeved Joint, Super Tough Construction, Tubeless Ready, 32 Hole |
Tyre: | Maxxis Assigai WT, TR, 2.5" 120TPI, EXO+ Casing, 3C Maxx Grip, Dual Compound, Front, Maxxis Minion DHR II WT, TR, 2.4" 120TPI, Double Down, 3C Maxx Terra, Dual Compound, Folding Bead, Rear |
Shift levers: | SRAM GX AXS, 2 Button, MMX, 12 Speed |
Front mech: | N/A |
Rear mech: | SRAM GX AXS, 12 Speed |
Cassette: | SRAM XG-1275 Eagle, 10-50, 12 Speed |
Chain: | SRAM GX Eagle, 12 Speed |
Crankset: | Whyte, Forged Alloy, 165mm, direct mount 36T |
Bottom bracket: | N/A |
Seatpost: | Crank Bro High-Line 3, 30.9mm, M/L 150mm, XL 170mm Travel, High-Line Ball Socket Remote Lever |
Saddle: | Fizik Terra Aidon, 145mm wide, Wingflex, S-Alloy Mobius rail |
Handlebar: | Whyte Custom 6061 Alloy, 30mm Rise, 35mm Bar Bore, 780mm Wide |
Stem: | Whyte Enduro Stem, 35mm Bar Bore, 35mm Extension |
Grips: | Whyte Lock-on Enduro Grip |
Brakes front: | SRAM Code R, 4 Piston with Sintered Metal Pads, 220mm Disc |
Brakes rear: | SRAM Code R, 4 Piston with Sintered Metal Pads, 200mm Disc |
Brake levers: | SRAM Code R, MMX |
Pedals: | None |
